Automatically checks design errors and
non-compliance against standards with one click

One click verifies tags, I/O, and logic to catch errors instantly.
It compares target logic with standards and highlights abnormal coils.
Clear reports give full visibility for quick fixes and prevention.

PLC eXpert

HOME
Platform
PLC eXpert

PLC Logic Verification Checklist

I/O Usage Check

Verifies how many I/O contacts are actually used in the logic.
Out of 4,681 total contacts, 1,667 were identified as unused.

Duplicate Coil Check

Identifies if a coil contact is used more than once.
In case of duplicates, only the last logic is valid; earlier ones are ignored.

Temporary Contact Check

Detects if temporary contacts remain in the program.
Tags like “TEMP” or “TEST” indicate temporary contacts (more can be added through settings).

Safety Interlock Check

Confirms that “Operation Ready” contacts are linked to “Emergency Stop.”
If not connected after operation ready, safety risks can occur.
Additional naming rules for operation ready/emergency stop can be added via settings.

I/O Usage Check

Verifies how many I/O contacts are actually used in the logic.
Out of 4,681 total contacts, 1,667 were identified as unused.

Duplicate Coil Check

Identifies if a coil contact is used more than once.
In case of duplicates, only the last logic is valid; earlier ones are ignored.

Temporary Contact Check

Detects if temporary contacts remain in the program.
Tags like “TEMP” or “TEST” indicate temporary contacts (more can be added through settings).

Safety Interlock Check

Confirms that “Operation Ready” contacts are linked to “Emergency Stop.”
If not connected after operation ready, safety risks can occur.
Additional naming rules for operation ready/emergency stop can be added via settings.

PLC Logic Verification Checklist

Tag Naming Check

Ensures tag names follow the defined standard language.
Since the check is based on registered standard symbols, results may change after updating settings.

SET/RST Balance Check

Verifies whether the number of SET and RST commands are equal.
If SET contacts outnumber or fall short of RST contacts, logic problems may occur.

Tag Naming Check

Ensures tag names follow the defined standard language.
Since the check is based on registered standard symbols, results may change after updating settings.

SET/RST Balance Check

Verifies whether the number of SET and RST commands are equal.
If SET contacts outnumber or fall short of RST contacts, logic problems may occur.
